indoor aluminum case led driver 12v 50w for LED bulbs strip light

Smart device surge protection for shortage, overload, over voltage high quality switch power Supply led driver 12v 50w widely used in Industrial automation, Elstarled 3528 led strip lighs.


  • Brand:

    SMARTS
  • Item No.:

    SMT-012-050SA
  • Input Voltage:

    100-240vac
  • Output Voltage:

    12V
  • Output Current:

    4.16A
  • Working Mode:

    cv
  • Dimming mode:

    non-dimmable
  • Size:

    112*88*34mm
  • Certification:

    ETL, CE, RoHS approval
Products description

indoor aluminum case led driver 12v 50w for LED bulbs strip light


With anti-jamming to ensures the long life LED lamps and reduce the LED luminous decay high quality switch led driver 12v 50w, widely used in LED display, Elstar non-waterproof 12v linear strip lights.

  Specification

Model

SMT-012-050SA

SMT-024-050SA

SMT-036-050SA

SMT-048-050SA







output

voltage

12V

24V

36V

48V

Voltage tolerance

±1%

±1%

±1%

±1%

Rated current

4.16A

2.08A

1.38A

1.04A

Current range

 0~4.16A

0~2.08A

0~1.38A

0~1.04A

Rated power

 50W

50W

50W

50W

Ripple&noise

150mvp-p

150mvp-p

150mvp-p

150mvp-p

DCvoltage ADJ.range

±10%

±10%

±10%

±10%





input

100~240Vdc

frequency

47~63HZ

efficiency

  83%

83%

83%

83%

Inrush current

Cold start current 18A/115VAC,36A/230VAC

Leakage current

< 1mA/240VAC



protection

Rated output power115%~150% start over load protection

environment

Working temp,humidity

-10°C~+60°C,20%~90%RH

Storagetemp,humidity

-20°C~+85°C,10%~95%RH non-condensing

Withstand vibration

10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes

safety

Withstand voltage

I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolated resistance

I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC

Fitstandard

Safety standard

Fit UL1012

EMC standard

Comply with EN55022,CLASSA

others

Dimension

112*88*34mm  (L*W*H)

Weight/packing

0.5kg/30pcs/15kg/0.335m³

note

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation

Click Send Email for Details
Click skpye 24 hours Online Reply
Scan to start our communication
Back to top


   Mechanical Specification

12 volt 50 watt led driver


  Compatible panel lights Type


Elstar SMD LED 5050 flex strip light features 50mm × 50mm surface mounted diodes, These large diodes are actually tri-chips, can produce three different colors of light simultaneously if together with led driver 12v 50w.


12 volt 50 watt led driver


  Related Products


12 volt 50 watt led driver
