12v 60 watt DMX512 dimmable led driver power supply for led strip lights
|
With the RDM (Remote Device Management) function, 100-277VAC, DMX512 Dimmable constant voltage 60w 12v led driver, can be set the different address by mobile Easy NFC APP or special NFC device to dim Alphabetlighting colorful leds lights. |
Specification
|
Model |
SMT-12060-XC-P |
SMT-24060-XC-P |
||
|
X=1 , 2 for DIM (DW); CCT(TW) |
||||
|
Output |
DC Voltage |
12V |
24V |
|
|
|
Voltage Tolerance |
±0.5V |
||
|
|
Voltage Regulation |
±0.5% |
||
|
|
Rated current |
CH1+CH2=5A |
CH1+CH2=2.5A |
|
|
|
Rated power |
60W (class 2 power units) |
||
|
|
Load Regulation |
±2% |
||
|
Input |
Voltage Range |
100-277VAC |
||
|
|
Frequency Range |
47 - 63Hz |
||
|
|
Power Factor（Typ.）@ full load |
PF≥0.98/ 230VAC (Full loading) |
||
|
|
THD（Typ.）@ full load |
<15% @120V 230V 277V |
||
|
|
Efficiency（Typ.）@ full load |
89% @230VAC |
87%@230VAC |
|
|
|
AC Current（Max.） |
0.8A |
0.8A |
|
|
|
Inrush Current （Typ.） |
36.4A,164us@50%Ipeak |
||
|
|
Leakage current |
<0.5mA |
||
|
Protection |
Short Circuit |
Hiccup mode, recover automatically after fault condition is removed |
||
|
|
Over Load |
≤120% ,hiccup model, recover automatically after fault condition is removed |
||
|
|
Over temperature |
≤100℃±10℃, shutdown output voltage, recover automatically after temperature drop |
||
|
|
Protection Class |
II |
||
|
Environment |
Working TEMP. |
-40～+60℃ (see below derating curve) |
||
|
|
Working Humidity |
20 - 90%RH ,non-condensing |
||
|
|
Storage TEM.,Humidity |
-40 - +80℃，10 - 95%RH |
||
|
|
TEMP.coefficient |
±0.03%/℃（0 - 50℃） |
||
|
|
Vibration |
10～500Hz, 2G 10min./1 cycle,period for 60min. each along X,Y,Z axes |
||
|
Safety&EMC |
Safety standards |
EN61347-1 EN61347-2-13 (EU) & UL8750 UL1310 (US) |
||
|
|
Withstand voltage |
I/P-O/P:3.75KVAC (EU) & I/P-O/P:1.5KVAC (US) |
||
|
|
Isolation resistance |
I/P-O/P：100MΩ/500VDC/25℃/70%RH |
||
|
|
EMC Emission |
EN55015 EN61000-3-2 EN61000-3-3 (EU) & FCC Part 15 B (US) |
||
|
|
EMC Immunity |
EN61000-4-2,3,4,5,6,11 EN61547 |
||
|
Others |
Net Weight |
0.35KG |
||
|
|
Dimension |
|||
|
|
packing |
280*210*160mm, 20pcs/ctn G.W.:7.6KG/CTN |
||
|
Notes |
1. All parameters NOT specially mentioned are measured at 230VAC input , rated load and 25℃of ambient temperature. 2. Tolerance: includes set up tolerance, line regulation and load regulation . 3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation, the final equipment manufactures must be-qualify EMC Directive on the complete installation again. |
|||
 |
 |
 |
 |
Mechanical Specification
Input terminal with 3P; Live Wire(L) , Neutral Wire (N) . Note: vacant for middle terminal
Suggested wire diameter: Primary 0.75-2mm² (18-14 AWG); Secondary 0.5-2mm² (20-14 AWG)
Output terminals with 6P; LED SEC positive (LED+), LED negative (LED-). Connected to LED light; Common anode design
2P for DIM (DW) dimming;
4P for CCT (TW) dimming with two LED positive pole
Please make sure you connect these correctly ,otherwise your product will not work correctly and could be damaged.
Note: there is external antenna at output side. Don't disassemble!
Compatible RGB strip Led Type
EEEkit 16.4ft RGB LED multi-color changing strip Light features 44 key IR remote controller and 60w 12v led driver. This super bright LED strip light is designed with 3528 SMD LED, features high intensity and reliability.
