UL DALI 2 pwm dimmable led driver 24v 150w constant voltage led lamp power supply

DALI 2 push DT 6 dimmable led driver 24v 150w  Engineered for durability for reliable performance in varying environments.
  • Brand:

    SMARTS
  • Item No.:

    SMT-JB24150V-DP2
  • Input Voltage:

    100-277Vac
  • Output Voltage:

    12VDC/24VDC/36VDC/48VDC
  • Working Mode:

    Constant Voltage
  • Dimming mode:

    DALI 2&PUSH Dimmable
  • Size:

    293*125*40mm
  • Certification:

    UL
Products description

UL DALI 2 pwm dimmable led driver 24v 150w constant voltage led lamp power supply


SMARTS DALI 2 DT6 dimmable 12V 24V led lamp power supply 150W Multiple protection features for overcurrent, overvoltage, and short circuit.Ensure the stable operation of lamps

led driver 24v 150w

  Specification

Model SMT-JB12150V-DP2 SMT-JB24150V-DP2 SMT-JB36150V-DP2 SMT-JB48150V-DP2
Certificate UL/cUL/SELV / CE
Output DC Voltage 12V 24V 36V 48V
Voltage range(adjust by NFC) 12-13.5V 24-26V 36-38V 48-50V
Voltage Tolerance ±0.5V
Voltage Regulation ±0.5%
Rated current 12.5A 6.25A 4.17A 3.13A
Rated power 150W
Load Regulation ±2% ±1% ±1% ±1%
Input Voltage Range 100-277VAC
Frequency Range 47 - 63Hz
Power Factor (Typ.) @ full load 0.98@120VAC          0.95@277VAC
THD(Typ. ) @ full load ≤10%@120VAC       ≤15%@277VAC
Efficiency(Typ.) @ full load

91%@120VAC

92%@277VAC

92%@120VAC

93.5%@277VAC

92.5%@120VAC

93.5%@277VAC

92.5%@120VAC

93.5%@277VAC

AC Current (Max.) 1.7A
Inrush Current (Typ.) 38.4A, 50%, 510us @120VAC    48A, 50% , 560us @277VAC
Leakage current <0.5mA
Protection Short Circuit Hiccup mode, automatically recover after fault condition removed
Over temperature 55℃±10℃ shut down o/p voltage, automatically recover after temp. drop.
Over Load ≤120% ,hiccup mode, recover automatically after fault condition is removed
Environment Working TEMP. -40~+60℃ (see below derating curve)
Working Humidity 20 - 90%RH  non-condensing
Storage TEM.,Humidity -40 - +80℃,10 - 95% RH non-condensing
TEMP.coefficient ±0.03%/℃(0 - 50℃)
Vibration 10~500Hz, 5G 10min./1 cycle, period for 60min. each along X,Y,Z axes
Safety & EMC Safety standards EN61347-1; EN61347-2-13 UL8750
Withstand voltage I/P-O/P:1.80KVAC   I/P-FG:1.80KVac  O/P-FG:1.80KVac
Isolation resistance I/P-O/P:100MΩ/500VDC/25℃/70%RH
EMC Emission EN55015 EN61000-3-2 EN61000-3-3   FCC Part 15 Subpart B
Others Net Weight 1.135Kg
Dimension 293*125*40mm (L*W*H)
Packing 330*300*215mm    20pcs /CTN
Notes 1.All parameters NOT specially mentioned are measured at 120VAC input, rated load and 25℃of ambient temperature.
2.Under low input voltage, reduced output is required to ensure a long life.

Click Send Email for Details
Click skpye 24 hours Online Reply
Scan to start our communication
Back to top


led driver 24v 150w


  Mechanical Specification



1. Input 3*18AWG,Black cable (L), White cable (N) and Green cable (G).

2. Output 2*16AWG (12V) 2*18AWG (24V, 36V,48V) Black cable (V+) connect to positive(+), Red cable(V-) connect to negative(-).

3. Dimming wire 2*18AWG Purple cable(L), Pink cable (N).

Warm tips Any other requests for cable, we can customized.

Dimming cable

Dimming electronic cable 3*18AWGBrown DA/N and Purple DA/L (No polar) connected to the DALI BUS when use DALI function.

Brown (N) is connected to AC (N) while Purple (L) and pink connected to Push dim switch dimmer( L) when use Push function.

※Please make sure you connect these correctly otherwise your product will not function correctly and could be damaged.

Note:  there is external antenna at output side.  Don't disassemble!



 Dimming Operation




Note: For DALI Dimming Wiring Diagram 3, please noted that only one DALI power is need in the DALI bus, so no extra DALI power is needed if the Master or Dimmer already includes the DALI Power.



 Dimming Operation

led driver 24v 150w

The default address for the DALI-2 LED driver is 001.

Address settings device:

Address settings:

① RDM setting address:

Set the address by the RDM device. For detailed operation, please refer to RDM device instruction manual.

② NFC setting address:

The DALI-2 led drivers’ address can be read and written by a mobile with NFC APP or NFC handheld device (NFC read & write device: NFC-RW) by close to the NFC signal area of the DALI-2 LED drivers


Adjust output voltage Operation

Adjust output voltage slightly for DALI-2 LED drivers

1) The driver output voltage can be read and written by a mobile with NFC APP or NFC handheld device (NFC read & write device: NFC-RW) by close to the NFC signal area of the DALI-2 LED drivers

2) Voltage range: level 1~10, each level is 0.2V. The default output voltage level is 1

Rated Vol.

Level 1

Level 2

Level 3

Level 4

Level 5

Level 6

Level 7

Level 8

Level 9

Level 10

12V

12.00V

12.16V

12.32V

12.48V

12.64V

12.80V

12.96V

13.12V

13.28V

13.50V

24V

24.00V

24.22V

24.44V

24.66V

24.88V

25.1V

25.32V

25.54V

25.66V

26.00V

36V

36.00V

36.22V

36.44V

36.66V

36.88V

37.10V

37.32V

37.54V

37.66V

38.00V

48V

48.00V

48.44V

48.44V

48.66V

48.88V

49.10V

49.32V

49.54V

49.66V

50.0V


Simple operation about DALI-2 LED driver address reset and adjusting output voltage slighting by a mobile with NFC APP (set NFC) or NFC handheld device (NFC read & write device: NFC-RW)

Ø Mobilephone NFC APP setting:
