277vac 300w class 2 led power supply for garden lights

The dimming range would be 0~100% and loading range:10~100% for 277vac class 2 power supply is a great item for COXO 5050 & 2835 led strip lights .
  • Brand:

    SMARTS
  • Item No.:

    SMT-012-300VTD52
  • Input Voltage:

    100-277vac
  • Output Voltage:

    12vdc/24vdc
  • Output Current:

    25A/12A
  • Working Mode:

    Constant voltage
  • Dimming mode:

    triac +0-10v dimmable
  • Size:

    303*78*47mm
  • Certification:

    CE UL ROHS FCC CLASS 2
Products description

277vac 300w class 2 led power supply for garden lights


It is fast, easy, and secure installation for the 300-watt low voltage transformer features a toroidal core from the led factory transformer and control receptacles - perfect for 300w LED spot light for AMP lighting.


  Specification


Model

SMT-012-300VTD52

SMT-024-288VTD52

Output

DC Voltage

12V

24V

Voltage Tolerance

±0.5V

Voltage Regulation

±0.5%

Voltage Tolerance

±0.5V

Load Regulation

±1%

±1%

Rated current

12.0A (3*4A)

25.0A (5*5A)

Rated power

288W (3*96W)

300W (5*60W)

Input

Voltage Range

100-277VAC

Frequency Range

4763HZ

Power FactorTyp.@ full load

0.99@120VAC  0.94@277VAC

0.99@120VAC  0.94@277VAC

THDTyp.@ full load

<20%

Inrush Current Typ.

35A ,50%,960us @120VAC ;  43A,50%,1ms @277VAC

Full Load  EfficiencyTyp.

87%@120V   91%@277VAC 79%

85%@120V   90%@277VAC

AC CurrentTyp.

3.4A@100VAC

3.6A@100VAC

Leakage current

<0.50mA

Protection

Short Circuit

shut down o/p voltage, re-power on to recover after fault condition is removed

Over load

≤120% constant current limiting, auto-recovery

Over temperature

100℃±10℃ shut down o/p voltage, automatically recover after cooling.

Environment

Working TEMP.

-40+60℃

Working Humidity

2090%RH,non-condensing

Storage TEM.,Humidity

-40+80℃1095%RH

TEMP.coefficient

±0.03%/℃050℃

Vibration

10500Hz 2G 10min./1 cycleperiod for 60min.each along X,Y,Z axes





Safety&EMC

Safety standards

UL8750+UL1310

Withstand voltage

I/P-O/P:1.88KVAC

Isolation resistance

I/P-O/P:100MΩ/500VDC/25℃/70%RH

EMC EMISSION

FCC 47 CFR Part 15 ,Subpart B

Others

Weight

1.90Kg

Size

303*78*47mm (L*W*H)

packaging

10PCS/CTN 385*335*200mm     20PCS/CTN

Notes

1. All parameters NOT specially mentioned are measured at 110V & 277VAC input , rated

  load and 25℃of ambient temperature.

2..Tolerance:includes set us tolerance,line regulation and load regulation.

Click Send Email for Details
Click skpye 24 hours Online Reply
Scan to start our communication
Back to top



  Mechanical Specification


led ceiling light driver



Input terminals "Black" and "White" to connect to AC L and N.

Output terminals "Red" to LED Positive side (+) , "Black"  to LED Negative side (-).


  Compatible LED rope lights Type


This garden lights power supply which makes Birddog Lighting your garden more coloful, romantic and warm, when you enter the pathway to your home with the 2 Color Blue & Cool White LED Rope Light - 120 Volt .


LED rope lights
